5G UPGRADE EJV
Parap, NT 0820, Australia
eJV Antenna, RRU and ancillary upgrade work on an existing rooftop steel structure. To produce Construction drawing for proposed scope with new steel structure.
CHALLENGES
Existing steel structure dimensions not available
Solution: Conducted site audit to capture all unknown measurements
Impact: Accurate assessment without assumptions
Â
CHS member thickness unknown
Solution: Used conservative thickness + minor strengthening
Impact: Ensured safe and stable structural performance
Â
Minor weld crack at joint
Solution: Advised NDT; recommended removal & rewelding
Impact: Restored joint integrity and safety
Â
Corrosion on existing bracing
Solution: Kept bracing; added new supplemental bracing
Impact: Improved frame durability and stability
TECHNICAL HIGHLIGHTS
Technologies: 4G/5G
Tools & Platforms : AutoCAD
Innovations / Optimizations: New strengthening proposed
Key Metrics: Minor crack observed and highlighted to client and proposed strengthening for better structure durability
DELIVERABLES
- Final DFC
- Structural certificate
- Strengthening detail drawing
Key Highlights:
4G/5G
Multi-technology rooftop upgrade
03
Structural issues identified & resolved
01
Site audit conducted for measurements
03
Engineering deliverables provided
01
New strengthening design proposed
100%
Structural verification completed
CONCLUSION
Our solutions added real value by improving safety, durability, and upgrade readiness. The project was delivered with precise assessments and smart, practical engineering decisions
We’re ready to apply the same expertise and thoughtful problem-solving to your next project.
